Victron Energy Victron SmartShunt Battery Monitor 500A 50mV

Check on your batteries

The Victron SmartShunt Battery Monitor is an all-in-one battery monitor that allows you to check on your batteries through your phone instead of a built-in display. The SmartShunt connects via Bluetooth to the VictronConnect App on your phone (or tablet). You can then conveniently read out all monitored battery parameters, like state of charge, time to go, historical information and much more!

Alternatively, the Victron SmartShunt Battery Monitor can be connected and be read by a GX device. Connection to the SmartShunt is made via a VE.Direct cable. The SmartShunt is a great alternative to a BMV monitor, especially for systems where battery monitoring is needed but you want less wiring and clutter. It’s equipped with Bluetooth, a VE.Direct port and a connection that can be used for: monitoring a second battery, midpoint monitoring or a temperature sensor. Keep track of your batteries. Grab a Victron SmartShunt Battery Monitor.

Victron SmartShunt Battery Monitor Features:

• All-in-one battery monitor
• Uses phone as display
• Connects via Bluetooth to the VictronConnect App
• Phone app conveniently displays all monitored battery parameters like state of charge, time to go, historical information and more
• Can also be connected and read by a GX device
• Great alternative to a BMV battery monitor
• Less wiring and clutter
• Equipped with Bluetooth, VE.Direct port
• VE.Direct port can be used for monitoring a second battery, midpoint monitoring or a temperature sensor

Victron SmartShunt Battery Monitor Specifications:

• Model: SHU050150050
• Supply voltage range: 6.5 – 70 VDC
• Current draw:
• Input voltage range, auxilliary battery: 6.5 – 70 VDC
• Battery capacity: 1 – 9999 Ah
• Operating temperature range: -40 to +50deg C (-40 to 120deg F)
• Measures voltage of second battery or temperature or midpoint: Yes
• Temperature measurement range: -20 to +50deg C
• VE.Direct communication port: Yes

Resolution and Accuracy

• Current: +/- 0.1A
• Voltage: +/- 0.01V
• Amp hours: +/- 0.1Ah
• State of charge (0 – 100%): +/- 0.1%
• Time to go: +/- 1 min
• Temperature (if optional temperature sensor connected): +/- 1deg C/F (0 to 50deg C or 30 to 120deg F)
• Accuracy of current measurement: +/- 0.4%
• Offset: Less than 20 / 40 / 80 mA
• Accuracy of voltage measurement: +/- 0.3%

Installation Dimensions

• Dimensions (H x W x D): 46 x 120 x 54mm
• Protection category: IP21

Standards

• Safety: EN 60335-1
• Emission / Immunity: EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
• Automotive: EN 50498
• Cables included: Two cables with 1A fuse for ‘+’ connection and starter battery or midpoint connection

Victron SmartShunt Battery Monitor 500A 50mV Product Manual
